The following installation and sizing guidelines are intended to support you with setting up the IGEL Universal Management Suite environment – UMS Server, UMS Console & UMS Web App, database, and, if required, load balancer and ICG instances.

General Installation Recommendations

For small installations, a single UMS Server instance (standard UMS) with an embedded database is usually sufficient. If required, a single-instance installation can be easily extended anytime to a Distributed UMS installation by installing additional servers (and in the case of an embedded database, by switching preliminarily to an external data source).

Large installations should use either the UMS High Availability or the Distributed UMS (preferable for new installations, e.g. because you do not have to configure additional firewall exclusions). For large installations, it is also recommended to use DNS-Round-Robin load balancing or IGEL Cloud Gateway.

For more information, see Installing a UMS server.

Installation Size#Devices

#UMS Server Host (+ Load Balancer)

UMS Server UMS Console Standalone #Load Balancer StandaloneLoad Balancer Standalone Database**ICG
S< 5.000

1 server


8 GB RAM
(UMS Web App + 1 GB)

4 CPUs

25 GB free disk space

Optional*

3 GB RAM

2 CPUs

1 GB HDD



Embedded database




1 ICG instance per 2,500 devices



Server generally:
8 GB RAM
2 CPUs
20 GB HDD

Only ICG service:
2 GB RAM
2 CPUs
2 GB HDD




M< 15.000

1 server


8 GB RAM
(UMS Web App + 1 GB)

4 CPUs

25 GB free disk space

Optional*

3 GB RAM

2 CPUs

1 GB HDD



External database

10 GB

M / S (HA or Distributed UMS)< 15.000

2 servers

2 load balancers

9 GB RAM
(Web App +1GB)

6 CPUs

25 GB HDD

Optional*

3 GB RAM

2 CPUs

1 GB HDD



External database

10 GB

L (HA or Distributed UMS)< 50.000

2 servers

2 load balancers

6 GB RAM***
(Web App +1GB)

4 CPUs

25 GB HDD

Mandatory

3 GB RAM

2 CPUs

1 GB HDD



External database

10 GB

XL (HA or Distributed UMS)****< 300.000

Up to 6 servers
(1 server / 50,000 devices)

9 GB RAM
(Web App +1GB)

6 CPUs

25 GB HDD

Mandatory

6 GB RAM

4 CPUs

1 GB HDD

Up to 3 Load Balancer
(1 LB / 3 Server)

4 GB RAM

4 CPUs

2 GB HDD

External database

20 GB


* UMS Console can be installed on UMS Server host.

** Follow the recommendation of the external database system on RAM and CPU.

*** RAM and CPU requirements are less than in the case of M / S (HA) installation since the UMS Console is installed on a separate host machine (UMS Console Standalone = Mandatory).

**** General recommendation: 1 UMS Server per 50,000 devices, 1 load balancer for 3 UMS Servers.
